Description
A durable, portable wire feed welder that’s great for auto repair, home or farm projects. Runs on 115V input power, welds up to 1/4 in. mild steel and is flux-cored or MIG ready.
Self-resetting motor protection
Protects wire feed system from overload, you won't need to change or reset the circuit breaker.
Arc Performance
Smooth, stable arc on all thicknesses allows you the best arc possible.
Industrial cast aluminum wire drive system
Durable wire feed provides you professional performance.
Five-position voltage control
Five voltage ranges allow you to fine-tune the arc.
Quick Select drive roll
Less of your time consumed in setup by offering three grooves - two for different size solid wire and a third for flux-cored wire.
Weighs only 57 pounds
Easier to transport: increased ability to weld where you need to weld.
Convenient polarity changeover
Easier and quicker for you to change polarity between solid or tubular wire.
Sloped control panel
Increased visibility so you can make adjustments more easily.
Self- resetting thermal overload protection
Protects power transformer from thermal overload to provide you maximum reliability.
What's Included
-
Comfortable 10 ft. (3 m) HR-100 gun
-
Owner's manual with installation, operation and maintenance guidelines.
-
10 ft. (3 m) work cable with clamp
-
Built-in gas solenoid valve and dual-gauge regulator with gas hose
-
Spool hub assembly accommodates 4 or 8 in. spools
-
Sample spool of .030 in. (0.8mm) self-shielding flux-cored wire
-
.030 in. (0.8mm) contact tips
-
Quick Select™ drive roll for .024 in. (0.6mm) or .030/.035 in. (08/.9 mm) solid wire, and .030/.035 in. (0.8/0.9 mm) flux-cored wire
-
Power cord with plug
-
Welding guide and material thickness gauge
General Specifications
| Title | Handler® 140 MIG Welder |
|---|---|
| Applications | Welding Projects |
| Industries | Farm and Ranch Auto Repair |
| Amperage | 25 A - 140 A |
| Material Thickness | Mild Steel 24 ga. (0.5 mm) - 1/4 in. (6.4 mm) |
| Weldable Metals | Aluminum Stainless Steel Steel |
| Current Type | DC |
| Rated Output | 90 A @ 20% duty cycle |
| Max Open Circuit Voltage | 28 VDC |
| Wire Feed Speed | 40 IPM - 700 IPM |
| Wire Diameter | Stainless 0.024 in. - 0.035 in. Stainless 0.6 mm. - 0.9 mm. Solid Steel 0.6 mm. - 0.9 mm. Solid Steel 0.024 in. - 0.035 in. Flux Cored 0.03 in. - 0.035 in. Flux Cored 0.8 mm. - 0.9 mm. |
| Portability | Handle(s) |
| Weld Output | CV |
| Input Voltage | 110/115/120 V |
| Input Phase | 1-Phase |
| Input Hz | 60 Hz |
| Net Width | 10.625 in |
| Net Height | 12.375 in |
| Net Length | 19.5 in |
| Net Weight | 57 lbs |
| Warranty | 3 Years Hobart Warranty |
